DOOR PARTS
For Model: SF216LXSQ1, SF216LXSM1
(Designer White) (Metalic)
14
Illus
No.
Part
No.
DESCRIPTION
Illus
No.
Part
No.
DESCRIPTION
Illus.
No.
Part
No.
DESCRIPTION
1
8533843 Screw
8
98015442 Glass, Outer
14
Screw (3)
2 W10111139Insulation (2)
9 W10109950Glass, Inner
98006727 White
3
98015563 Liner, Door
10
Handle, Oven Door
98006726 Black
4 W10111696Insulation, Door
98004940 White
15
Retainer
5
Clip, Glass
98004939 Black
98004564 Right
98004952 Left
11
98008699 Screw (2)
98004629 Left
98004953 Right
12
98004993 Screw (4)
16
98015365 Support, Glass (2)
6
98017875 Hinge, Door (2)
13
Insulation, Side
17
98004219 Screw
7
Panel, Door
W10110943Left
18
98004650 Nut, Push (2)
98015017WWhite
W10110944Right
19
98015806 Retainer, Insulatn
98015017LMetalic
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
8
W10143251
