The seven-wire harness contains
the following trailer circuits:
• Yellow: Left Stop/Turn Signal
• Dark Green: Right Stop/Turn
Signal
• Brown: Taillamps
• Black: Ground
• Light Green: Back-up Lamps
• Red/Black: Battery Feed
• Dark Blue: Trailer Brake*
*The fuse for this circuit is installed
in the underhood electrical center,
but the wires are not connected.
They should be connected by your
dealer/retailer or a qualified service
center.
If the back-up lamp circuit is not
functional, contact your dealer/
retailer.
If a remote (non-vehicle) battery is
being charged, press the Tow/Haul
mode switch located on the center
console near the climate controls.
This will boost the vehicle system
voltage and properly charge the
battery. If the trailer is too light for
Tow/Haul mode, turn on the
headlamps (Non-HID only) as a
second way to boost the vehicle
system and charge the battery.
Electric Trailer Brake Control
Wiring Provisions
These wiring provisions for an
electric trailer brake controller
are included with the vehicle as
part of the trailer wiring package.
The instrument panel contains
blunt cut wires behind the
steering column for the electric
trailer brake controller.
The harness contains the following
wires:
• Red/Black: Power Supply
• White: Brake Switch Signal
• Gray: Illumination
• Dark Blue: Trailer Brake Signal
• Black: Ground
The electric trailer brake controller
should be installed by your dealer/
retailer or a qualified service center.
Engine Cooling When Trailer
Towing
The cooling system may temporarily
overheat during severe operating
conditions. See Engine Overheating
on page 5-22.
4-32 Driving Your Vehicle
