SET-UP GUIDE

DASHBOARD CONTROL PANEL

POWER

BASS/TREBLE

VOLUME

INPUT

OUTPUT

USB CHARGING PORT

USB POWER PORT

BASS/TREBLE

POWER SWITCH / VOLUME CONTROL

LED POWER INDICATOR

RCA AUDIO INPUT

HEADPHONE JACK

RCA AUDIO OUTPUT

Dimensions:

25 in. L x 17.75 in. W x 32.5 in. H

63 cm. L x 45 cm. W x 83 cm. H

2 x 2.75 in. (7 cm) coaxial mid-high speakers @ 2W 4 Ohms
4 in. (10 cm) sub-woofer speakers @ 5W 8 Ohms

SYSTEM SPECS:

The BOOMCHAIR

comes with the following:

PARTS LIST:

1) RPM BOOMCHAIR

2a) RCA Y-AUDIO ADAPTOR

2b) AUDIO CORD

2c) RCA CORD (audio left & right channel connectors)

3) SPEAKERS

4) HOOK & LOOP FASTENER

5) ADJUSTABLE RECLINE STOPPERS

6) DASHBOARD CONTROL PANEL

7) POWER RECEPTACLE

8) 12V POWER ADAPTOR

9) ADJUSTABLE MASSAGE PILLOW

(2 AA BATTERIES REQUIRED, NOT INCLUDED)

Wireless Kit

W1)

WIRELESS TRANSMITTER

W2)

WIRELESS RECEIVER

W3)

Y - ADAPTOR

W4)

5VDC MINI USB POWER ADAPTOR

W5)

1/8 in. (3.5mm) AUDIO CORD - SHORT

W6)

1/8 in. (3.5mm) AUDIO CORD - LONG

W7)

USB TO MINI USB POWER CORD

* WIRELESS KIT SOLD SEPARATELY. TO PURCHASE VISIT WWW.BOOMCHAIR.COM

TRANSMITTER

RECEIVER

Wireless Kit
