BoomChair B51 - Manual (Page 9)

DAISY CHAINING CHAIRS TOGETHER : up to 4 chairs
9
Step 1:
Step 2:
Step 3:
Step 4:
Connect single end of first “Y” adapter to RED RCA plug coming from media device. (Fig.1)
Connect single end of second “Y” adapter to WHITE RCA plug coming from media device. (Fig.2)
Cord A (Fig.3): Connect RED plug to RED “Y” adapter and WHITE plug to WHITE “Y” adapter. Seperate
cords as necessary. Connect opposite end of cord to INPUT of first BoomChair™.
Cord B (Fig.4): Connect RED plug to RED “Y” adapter and WHITE plug to WHITE “Y” adapter. Seperate
cords as necessary. Connect opposite end of cord to INPUT of second BoomChair™.
Media Device or TV
IN
IN
RCA “Y” ADAPTER
(sold seperately)
RCA CORD (3b)
3b
FIRST CHAIR
SECOND CHAIR
Fig. 1
Fig. 2
Fig. 3
3b
Fig. 4
Note: You will need two RCA “Y” adapters (sold seperately) and two RCA cords (3b) to connect two BoomChairs
Audio OUT
