Set-up guide dashboard control panel, Wireless kit – BoomChair A44 - 2nd Generation User Manual
Page 3
3
POWER
VIBRATION
VOLUME
INPUT
OUTPUT
USB CHARGING PORT
SYSTEM SPECS:
The BOOMCHAIR
®
comes with the following:
PARTS LIST:
1) A44 BOOMCHAIR
®
2a) RCA Y-AUDIO ADAPTOR
2b) AUDIO CORD
2c) RCA CORD (audio left & right channel connectors)
3) ADJUSTABLE HEADREST
4) SPEAKERS
5) HOOK & LOOP FASTENER
6) ADJUSTABLE RECLINE STOPPERS
7) POWER RECEPTACLE
8) 5V POWER ADAPTOR
9) DASHBOARD CONTROL PANEL
10) MESH POCKET
Wireless Kit
*
W1)
*
WIRELESS TRANSMITTER
W2)
*
WIRELESS RECEIVER
W3)
*
Y - ADAPTOR
W4)
*
5VDC MINI USB POWER ADAPTOR
W5)
*
1/8 in. (3.5mm) AUDIO CORD - SHORT
W6)
*
1/8 in. (3.5mm) AUDIO CORD - LONG
W7)
*
USB TO MINI USB POWER CORD
* WIRELESS KIT SOLD SEPARATELY. TO PURCHASE VISIT WWW.BOOMCHAIR.COM
W2
W3
TRANSMITTER
RECEIVER
W4
W5
W7
W6
Wireless Kit
W1
SET-UP GUIDE
DASHBOARD CONTROL PANEL
2a
2b
2c
3
1
4
9
5
7
6
8
10
Dimensions:
26 in. L x 17 in. W x 31 in. H
66 cm. L x 43 cm. W x 79 cm. H
2 x 3 in. (7.5 cm) coaxial mid-high speakers @ 3W 4 Ohms
USB POWER PORT
VIBRATION
POWER SWITCH / VOLUME CONTROL
LED POWER INDICATOR
RCA AUDIO INPUT
HEADPHONE JACK
RCA AUDIO OUTPUT
