CONTROL PANEL OPERATING PROCEDURES
Table 3-6.
Relationship Between Air/Fuel Valve Position and Energy Input For Unit Running On Natural Gas
Fire Rate,
Air/Fuel Valve
Position
(% Open)
Energy Input
(BTU/Hr)
Boiler Energy Input
(% of Full Capacity)
0 0 0
10% 0 0
18%
(Stop Level) 100,000
5.0%
20% 134,000 7%
30% 349,000 17%
40% 631,000 32%
50% 893,000 45%
60% 1,150,000 58%
70% 1,410,000 71%
80% 1,610,000 81%
90% 1,830,000 92%
100% 2,000,000 100%
