7 A-16D A-N
et
D
istributor
u
ser
G
uiDe
Type: Switching
Input Voltage: 90‑240 volts 50/60Hz 30VA
Output: 24Vdc 0.5A
Polarity Outer = negative; Inner = positive
Plug Size 2 mm
_
+
Power Supply Polarity
Note that polarity of the plug found on the DC power supply needs to match
that of the original power supply that came with your Aviom equipment.
Aviom products use a center positive power supply. The outer contact is
negative, the inner contact is positive. (See the diagram above.)
Rack Mounting
The A‑16D A‑Net Distributor can easily be mounted in a standard 19‑inch
wide equipment rack. The A‑16D occupies half of the rack width, allowing
two A‑16D units to be placed side by side on a standard rack shelf. These
shelves are available as an accessory from many audio and studio suppliers.
There are two shelf‑mounting holes in the bottom panel of the A‑16D. The
holes accept a 6‑32 size bolt. The depth of the hole in the A‑16D bottom
panel is 0.25 inches (6.35 millimeters). Do not insert more than 0.25 inches of
thread into the mounting holes on the bottom of your A‑16D Distributor.
CAUTION!
Be careful when selecting mounting hardware for use with your accessory
shelf. Using bolts that are too long can damage the circuit board of your
A‑16D.
Use of improper mounting hardware will void your warranty.
Always allow adequate ventilation for devices mounted in equipment
racks. Avoid placing your Pro16 product directly above or below other rack‑
mounted devices that produce high levels of heat, such as power amps.
