Specifications )
TC»14SV10S,TC-21SV10S
TC-21SV10M,TC-14SV10M
TC-21SV10H, TC-14SV10H
Power Source
AC 110-240 V, 50/60 Hz
AC22Q-240V, 50 Hz
AC 200-220 V, 50 Hz
Power Consumption
TC-21SV10S. TC-21SV10M, TC-21SV10H
114 W
Stand-by condition
41 W (VCR REC)
5 W (VCR STOP)
TC-14SV10S, TC-14SV10M, TC-14SV10H
SOW
Stand-by condition
41 W (VCR REC)
5 W (VCR STOP)
Receiving Systems
System
TC-14SV10S
TC-14SV10M
TC-14SV10H
Function
TC-21SVIOS
TC-21 SVI OM TC-21SVIOH
1.
PAL B, G, H
O
o
-
Reception of broadcast
2.
PAL!
o
transmissions and pfay
3.
PAL D. K
o
-
o
back from video Cas-
4.
SECAM B, G
o
—
-
sette Tape Recorders
5.
SECAM D, K
o
-
-
6.
SECAM K1
o
7.
NTSC 4.43 / 5.5 MHz
o
o
8.
9.
NTSC 4.43 / 6.0 MHz
NTSC 4.43 / 6.5 MHz
o
o
o
Playback from Special
VCR’s
10.
NTSC 3.58 / 5.5 MHz
o
o
-
11.
NTSC 3.58 / 6.0 MHz
-
o
12.
NTSC 3.58 / 6.5 MHz
o
—
o
13.
14.
15.
PAL 60Hz / 5.5 MHz
PAL 60Hz / 6.0 MHz
PAL 60Hz / 6.5 MHz
o
o
o
Ò
o
Playback from Special
Disc Player's and
Special VCR’s
Receiving Channels
TC-14SV1 OS, TC-21SV10S
VHP
2-12 (PAL/SECAM B, K1)
1 -12 (PAL/SECAM D)
UHF
21 - 69 (PAL G. H, I
SECAM G, K, K1)
13-57 (PALD, K)
CATV
SI - S20 (OSCAR)
S21 -S41 (HYPER)
Z1 - Z37 (CHINA)
TC-14SVi OM; TC-21SV1OM;
VHP
2 - 1 2 (PAL B)
0 - 1 2 (PAL B AUSTRALIA)
1 - 9 (PAL B N. ZEALAND)
UHF
21 - 69 (PAL G. H)
28 - 69 (PAL B AUSTRALIA)
CATV
SI - S 2 0 (OSCAR)
S21 - S 4 1 (HYPER)
5 A - 9 A (AUSTRALIA)
TC-21 SV10H,TC-14SV10H
VHP
1 -12 (PAL D)
UHF
21 -69 (PAL I)
1 3 - 5 7 ( P A L D , K)
CATV
SI - S20 (OSCAR)
S21 - S41 (HYPER)
Z1 - Z37 (CHINA)
Tuning System
Frequency synthesizer
Auto Search Tuning 60 Position
Picture Tube
TC-21SV10S, TC-21 SV10M, TC-21 SVI OH
Overall Picture tube measured diagonally
54 cm
Viewable Picture tube measured diagonally
51 cm
CRT deflection : 90 *
TC-14SV10S, TC-14SV10M. TC-14SV1 OH
Overall Picture tube measured diagonally
36 cm
Viewable Picture tube measured diagonally
34 cm
CRT deflection : 90 ®
Audio Output
3 W (max)
Headphones
impedance 8 ii, 3.5 mm Plug
Aerial Impedance
75 n Unbalanced coaxial
