SRECIHICATIONS
Pick-up Device:
Scanning Area:
Scanning:
Horizontal:
Vertical:
Synchronization:
Video Output;
Horizontal Resolution:
Signal-to-Noise Ratio:
Dynamic Range:
Minimum Illumination:
Gain Control:
White Balance:
Aperture:
Electronic Light Control:
Super D:
Electronic Shutter Speed;
Lens Mount;
ALC Lens:
Ambient Operating Temperature:
Ambient Operating Humidity;
771 (H) X 492 (V) pixels, Interline Transfer CCD
4.8 (H) X 3.6 (V) mm (Equivalent to scanning area of 1/3" pick-up tube)
525 lines / 60 fields / 30 frames
15.734 kHz
59.94 Hz
Internal, Line-locked, External (VS/VBS) or
Multiplexed Vertical Drive (VD2) Selectable
1.0 V[p-p] NTSC composite 75 il / BNC connector
480 lines
50 dB (AGC OFF, weight ON)
40 dB
0.9 lx (0.09 footcandle) at F0.75 [Equivalent to 3 lx (0.3 footcandle) at F1.4]
Selectable AGC ON or OFF (SET UP MENU)
Selectable ATW or AWC (SET UP MENU)
Set Variable (SET UP MENU)
Equivalent to continuous variable shutter speed between 1/60 s
and 1/10 000 s
Selectable On or Off (SET UP MENU)
Selectable 1/60 (OFF). 1/100, 1/250, 1/500, 1/1 000. 1/2 000, 1/4 000,
1/10 000 s
Selectable C-mount or CS-mount
Selectable DC or Video
-10X - -i-50°C (14“F - 122°F)
Less than 90%
-41-
