j Attaching the Support Trays
There are two identical support trays. One of the support trays holds paper as it comes out of the
face-down delivery slot. To install this support, insert the tabs into the corresponding slots above the
face-down delivery slot, making sure that the smaller tab is on the left.
The other support tray holds documents as they are fed into the Automatic Document Feeder (ADF).
To install this support, insert the tabs into the corresponding slots above the Automatic Document
Feeder (ADF), making sure that the smaller tab is on the left.
