PARTS DIAGRAM
SHG
The parts illustrated and listed
here are unique to the SHG
grinder. All other parts are
shared unless specified.
PARTS DIAGRAM MOTOR ASSY
The parts illustrated and listed here
are shared between both
the DHG and SHG
grinders.
7 8
9
3
4
5
1
6
1
2
4
3
19
5
6
1
2
3
4
5
6
7
7A
8
9
9A
MOTOR SLICING GRINDER ASSY 120VAC
KIT, GRINDER CHUTE NEW STYLE
CAPACITOR, COFFEE GRINDER ASSY
SHEAR DRIVE COFFEE GRINDER
DISC, SHEAR COFFEE GRINDER 6PCS
SCREW & THRUST PIN ADJUSTING ASSY
BURRS, SET CRUSH HIGH FLOW
BURR, COMPLETE SET SLICING
SPRING, TENSION COFFEE GRINDER
WORM FEEDING ASSEMBLY
FEEDWORM, SLICING GSG
WC-9135
WC-37283
WC-91026
WC-91024
WC-9107-6
WC-91015
WC-91045
WC-91050
WC-91021
WC-91020
WC-91051
WC-9129
WC-9117
WC-9165
WC-3891
WC- 101
WC- 628
COVER, TOP ASSEMBLY SHG
HOPPER, COFFEE BEAN SHG
COVER, FRONT SHG
LABEL, SHG
SWITCH, ON/OFF NON-LIT SPST MOMENTARY
TIMER, 120V .5-60 SEC SHG
DESCRIPTION ITEM № PART №
1
2
3
4
5
6
DESCRIPTION ITEM № PART №
