FOUNTAIN REASSEMBLY
1) Replace the motor into its location between the 4 half-inch posts
on the right side of the fountain. Gently push down to engage the
suction cups. (Fig. 3a & 3b)
Fig. 3a Fig. 3b
2) Thread the plug through the opening in the back left corner of
the bowl piece (Fig. 3c). Next, thread the cord along the back of
the fountain to the cord notch (Fig. 3d). Use this pass-through to
keep the cord from showing.
Fig. 3c Fig. 3d
Cord Notch Opening
Line up the filter housing unit over the motor and then the
bowl. You will want to line up the intake tube to fit directly into
the motor. Once in place, gently push down, locking the filter
housing into place.
3)
4)
5)
Replace the pre-filter over the flow
control knob by sliding the narrow end
in first. The lip on the top of the pre-filter
will be facing the front of the fountain,
push down to snap it into place over the
flow control knob. (Fig. 3e)
Replace the filter and housing lid.
Fig. 3e
