CHARGING OPTIONS: (continued)

Invert refrigerant tank (some tanks need not be inverted to dispense liquid

refrigerant). Open refrigerant tank supply valve and open the manifold’s red

“HI” side valve. After dispensing the proper amount of refrigerant, close the

manifold’s red “HI” side valve and close refrigerant tank supply valve.

Liquid Low Side Charging: To draw liquid from tank and charge into low

side. Turn the yellow “REF” valve fully clockwise to the “LOW SIDE LIQUID

CHARGE” position finger tight. Close the red “HI” side valve. Invert refrig-

erant tank (some tanks need not be inverted to dispense liquid refrigerant).

The compressor must be running. Open refrigerant tank supply valve and

open the manifold’s blue “LO” side valve. After dispensing the proper

amount of refrigerant, close the manifold’s blue “LO” side valve and close

refrigerant tank supply valve.

Vapor Low Side Charging: When drawing vapor from tank and charging

into system low side, turn the yellow “REF” valve fully counter-clockwise to

the “VACUUM, VAPOR, LIQUID HI SIDE” position, finger tight. Close the

red “HI” side valve. Compressor must be running. Open refrigerant tank

supply valve and open the manifold’s blue “LO” side valve. After dispensing

the proper amount of refrigerant close the manifold’s blue “LO” side valve

and close refrigerant tank supply valve.

4. When the system is operating properly, disconnect manifold by closing

both “HI & LO” valves - finger tight. Carefully remove the charging hoses

from the system.

REPLACEMENT PARTS LIST

Description:

For

P/N

Seal Kits (2)

High & Low Valve

600R

Spring

Mylar Disc

Diaphragm

Actuator

Washer
Handles & Stem Kits

High & Low Valve

602R

Handle (LO)

Handle (HI)

Stem (2) PIN 1000936
Control Valve Kit

Ref. Control Valve

700CV

Handle (REF)

Stem Assy (Stem/Tip/O-ring)

Bonnet

Bonnet O-ring
*Filter Connector

1/4 SAE

S10000800

5/16 SAE

S16003754

Boot Set

400RB

Red

Blue

*All port fittings equipped with

120 mesh filters. Filter connection

may be cleaned and rinsed in 91%

alcohol with O-ring removed.

PART NO. P0001613 Rev. B

30333 Emerald Valley Parkway • Glenwillow, Ohio 44139 USA

www.imperial-tools.com • [email protected] © 2010 Stride Tool Inc.

W

A

R

N

IN

G

CA

UT

IO

N

This manifold should only be used by experienced professional service techni-

cians in the refrigeration & air-conditioning field who are familiar with equipment

being serviced. Safety goggles should be worn at all times. Refrigerant and

lubricant vapor or mist may cause injury, frostbite, irritate eyes, nose and throat.

Avoid breathing or contact with skin. Always point hose away from you and

anybody near or around you. Remove hoses with care as they may be under

high refrigerant pressure. Improper procedures can cause refrigerant gas under

pressure to explode violently. Read all instructions before starting.
PROP 65 WARNING: This product contains chemicals, including lead,

known to the State of California to cause cancer, and birth defects or

other reproductive harm. Wash hands after use.

The Imperial Kwik-Charger manifold provides a safer, faster method
of charging CFC, HCFC, HFC, azeotropic and zeotropic blended
refrigerants into the low-pressure or suction side of a refrigerated
system. Zeotropic blended refrigerants (R-410A, R-404A, etc.) must
be charged as a liquid from the refrigerant cylinder. Great care must
be taken to avoid liquid slugging the compressor when charging into
the low side of a running system. The Kwik-Charger manifold
handles the process of charging liquid refrigerant into the system
low-pressure side with ease. Charge all refrigeration & air-
conditioning systems according to manufacturers specifications.

To use the Kwik-Charger for liquid low side charging, turn the “REF”
valve clockwise, until finger tight, to the “LOW SIDE LIQUID
CHARGE” position. This engages an internal metering element that
reduces liquid flow to a level below capacity of the compressor
assuring a safe fast charge. The compressor must be running. For
vapor charging from the tank, liquid high side charging or
evacuating, turn the “REF” valve counter-clockwise, until finger
tight, to the “VACUUM, VAPOR, LIQUID HI SIDE” position. In this position,
the internal metering device is disengaged, and the Kwik-Charger
manifold performs as a conventional manifold.

Charging liquid into the low side of the system without engaging the internal

metering element may slug the compressor and damage the system.

Always turn the “REF” valve clockwise, finger tight, to the “LOW SIDE

LIQUID CHARGE” position for liquid low side charging. The compressor

must be running during this process.

2-VALVE SYSTEM ANALYZER WITH REFRIGERANT CONTROL VALVE

Kwik-Charger

®

Service Manifold Operating Instructions
