Part List

IMPORTANT NOTE

Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.

We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Hardware List

Tools required for assembly :

Phillips screwdriver

D.
Back Frame

.

1 pc

F.

Side Stretcher

1 pc.

E.

Side Stretcher

1 pc.

Head Cap Bolt

4 pcs.(+1 extra)

Spring Washer
9 pcs.(+1 extra)

Flat Washer
9 pcs.(+1 extra)

Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319

[email protected]

Key Wrench

1 pc.

Head Cap Bolt

(long)

4 pcs.(+1 extra)

Wood Screw
6 pcs.(+1 extra)

Head Cap Bolt

(short)

1 pcs.(+1 extra)

B.

Leg

1 pc.

C.
Leg

1 pc.

G.

Front Stretcher

1 pc.

88 5

8

033 9

Small
Hex Wrench
1 pc.

A.
Seat
1 pc.

Nantucket

Bar Stool
