7.
VETTER Flexible packer
7.1 Vetter Flexible packer with frame
The adaptable solution
9
for pipelines with a diameter range of 150 mm to 600 mm
9
guaranteed stability due to mounted wheel sets
9
integrated ducts enable the water to flow out during the re-
pair work
Technical Data
Flexible packer
Application
range
(from - to)
mm /
inch
Packer
length,
approx.
mm /
inch
Application
length in
largest diam.
mm /
inch
Application
length in
smallest diam.
mm /
inch
Packer
diameter
mm /
inch
Packer length,
with carriage,
approx.
mm /
inch
Weight,
approx.
kg /
lbs
Type 150-250
1491045900
2.5 bar
(36.25 psi)
150 - 250
5.9 - 9.8
1,000
39
680
26.5
780
30.4
105
4.1
1,130
44.1
6.4
14.1
Type 150-250
1491046000
2.5 bar
(36.25 psi)
150 - 250
5.9 - 9.8
2,000
78
1,680
65.5
1,780
69.4
105
4.1
2,130
83.1
10
22.1
Type 150-250
1491046100
2.5 bar
(36.25 psi)
150 - 250
5.9 - 9.8
3,000
118
2,680
104.5
2,780
108.4
105
4.1
3,130
122.1
14
20.9
Type 150-250
1491046200
2.5 bar
(36.25 psi)
150 - 250
5.9 - 9.8
4,000
156
3,680
143.5
3,780
147.4
105
4.1
4,130
161.1
18
39.7
Type 200-300
1491044800
1.5 bar
(21.75 psi)
200 - 300
7.8 - 11.8
1,000
39
590
23
690
26.9
170
6.6
1,260
49.1
10
22.1
Type 200-300
1491046300
1.5 bar
(21.75 psi)
200 - 300
7.8 - 11.8
2,000
78
1,590
62
1,690
65.9
170
6.6
2,260
88.1
15
33.1
Type 200-300
1491046400
1.5 bar
(21.75 psi)
200 - 300
7.8 - 11.8
3,000
118
2,590
101
2,690
104.9
170
6.6
3,260
127.1
20
44.1
Type 200-300
1491046500
1.5 bar
(21.75 psi)
200 - 300
7.8 - 11.8
4,000
156
3,590
140
3,690
143.9
170
6.6
4,260
166.1
25
55.1
Type 300-400
1491044900
1.5 bar
(21.75 psi)
300 - 400
11.8 - 16
1,000
39
560
21.8
660
25.7
230
9
1,260
49.1
13.2
29.1
Type 300-400
1491046600
1.5 bar
(21.75 psi)
300 - 400
11.8 - 16
2,000
78
1,560
60.8
1,660
64.7
230
9
2,260
88.1
19.4
42.8
Type 300-400
1491046700
1.5 bar
(21.75 psi)
300 - 400
11.8 - 16
3,000
118
2,560
99.8
2,660
103.7
230
9
3,260
127.1
26
57.3
Type 300-400
1491046800
1.5 bar
(21.75 psi)
300 - 400
11.8 - 16
4,000
156
3,560
138.8
3,660
142.7
230
9
4,260
166.1
32
70.6
Type 400-600
1491045700
1.5 bar
(21.75 psi)
400 - 600
16 - 23.4
1,500
58.5
900
35.1
950
37.1
350
13.7
1,770
69
26.1
57.6
Standard through-flow openings of 2“.
All rights reserved for technical changes within the scope of product improvement.
