Craftsman POWER RAKE 486.2928 - Manual (Page 11)

11 Call 1-866-576-8388 for missing parts or assembly help
DO NOT RETURN TO STORE
reF ParT NO qTY deSCrIPTION
1 GB845-85 11 Screw
2 MDL8.253.058 1 Bottom Handle
3 MDL8.253.016 2 Connecting Bar
4 MDL8.253.044 1 Upper Handle
5 MDL8.212.007 1 Foam Grip
6 GB14-80 6 Carriage Bolt, M6 X 35
7 MDL8.253.053 6 Wing Knob
8 MDL8.194.025 1 Crossing Bar
9 MDL8.353.007 1 Switch Box 1
10 MDL8.353.008 1 Switch Box 2
11 MDL8.100.009 1 Pressing Board
12 MDL8.253.052 1 Switch Trigger
13 FA1-6/2B-A1 1 Switch
14 MDL8.369.001 2 Cable Jacket
reF ParT NO qTY deSCrIPTION
15 MDL8.281.029 1 Spring 2
16 MDL8.281.028 1 Spring 1
17 MDL8.100.002 2 Cord Grip
18 MDL3.460.006 1 Capacitor
19 MDL5.501.012 1 Cable
20 MDL5.501.016 1 Cable
21 MDL8.486.017 3 Power Cord Holder
22 MDL8.100.010 2 Handle Bracket
23 MDL5.355.006 1 Collecting Bag
24 MDL8074.014 1 Bag Support Clip
25 MDL8.233.006 1 Strap
26 MDL8.486.016 1 Cord Holder
27 R19131316 2 Washer
40946 1 Owners Manual
rePaIr ParTS LIST
MOdeL 486.29280
