175
By connecting the camera to a TV, you can view your shots on the larger
screen of the TV.
For details on connection or how to switch inputs, refer to the TV manual.
Connecting the camera to a TV with the AV Cable AVC-DC400 (sold
separately) enables you to view your shots on the larger screen of the TV as
you control the camera.
Make sure the camera and TV are
off.
Connect the camera to the TV.
z On the TV, insert the cable plugs fully into the
video inputs as shown.
z On the camera, open the terminal cover and
insert the cable plug fully into the camera
terminal.
Turn the TV on and switch to video
input.
z Switch the TV input to the video input you
connected the cable to in step 2.
Using Optional Accessories
Playback on a TV
• Some information may not be displayed when viewing images on a TV (p. 202).
Playback on a Standard-Definition TV
Still Images Movies
Yellow
White
Yellow
Red
Red White
