Arm SK-104C for Speedlights
SB-102, SB-103
Use the arm (SK-104C) to secure
the SB-102 or SB-103 to the
standard bracket or double bracket.
When connecting the SB-103, use a
wide adaptor to adjust the shooting
angle and flash angle.
Weight: Approx. 250g (8.8 oz) (on land)
Approx. 80g (2.8 oz) (underwater)
Front positioning
index
Arm positioning screw
Shoulder
joint lock'
-Shoulder joint
release button
Using the SK-104C arm for the SB-102 and SB-103
1
Insert the arm (SK-104C) Into the
joint attached to the SB-102 or
SB-103.
—For details on the joint and instructions
on its use, see the Instruction Manual for
the SB-102 or SB-103.
I Attach the arm to the double
bracket (SK-104W) in the same way
that the standard arm (SK-104A) is
attached to the standard bracket
(SK-104B). (See page 17.)
