ENGINE
TRACTOR - - MODEL NUMBER 917.274990
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 Engine (See Breakdown) Kohler 37 123487X Clamp Hose
Model No. CV674-7S544 39 17490636 Screw TT 3/8-16 X 2-1/4 UNC
2 149723 Muffler 40 17490664 Screw TT 3/8-16 X 4 UNC
8 121Э61Х Pulley V-ldler 41 1261Э7Х Washer 1-1/2 OD x 15/32 ID x
9 177748 Keeper Asm. Bell Engine .250
10 175287 Bushing 42 STD551143 Washer Lock 7/16
11 170056 Clutch Electric 43 173937 Bolt Hex 7/16 - 20 X 4 Ga 5
12 143996 Pulley Engine VGT Elect Clutch 47 175288 Bushing
15 151346 Tank Fuel Rear 3.50 YVGt 96 62 146629 Shield Heal Muffler
16 109227X Pad Spacer 69 24-041-02 Gasket
17 106082X Pad Spacer 70 175545 Tube Exhaust LH
18 161493 Cap Asm Fuel W/Gauge 71 175546 Tube Exhaust RH
20 177328X428 Control Throttle 74 162295 Elbow Street Brass
21 164863 Screw HWHD Hi-Lo #13-16x3/4 80 М7ЭОЭ0800 Nut Range
22 175441X428 Control Choke 81 148456 Plug Drain Oil Easy
24 STD551237 Washer Ext Tooth 3/8 82 148315 Plug Oil Drain Easy
25 73920600 Nut Keps3/8-24UNF 83 171877 Bolt 5/16-18 UNC X 3/4 W/ Sems
26 3645J Bushing 84 17060624 Screw3/8-16x 1-1/2
27 139277 Stem Tank Fuel
28 7834R FuelUne
29 137180 Spark Arrester Kit NOTE; All component dimensions given In U.S. inches
35 10010500 Washer Split 1 inch = 25.4 mm
43
