SCHEMATIC

TRACTOR - - MODEL NUMBER 917.270814

L0J

HEADUGHTS

IGNITION SWITCH

posmoN

CIRCUIT "HAKE"

OFT Q + M + L NONE

RliN/LIGHT B + L

A +Y

RUN

B + L

NONE

START B + L + S NONE

NOTE

YOUR TRACTOR IS

EQUIPPED WITH A SPECIAL

ALTERNATOR SYSTEM.
THE LIGHTS ARE NOT
CONNECTED TO THE
BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE.
BECAUSE OF THIS. THE
BRIGHTNESS OF THE LIGHTS

WILL CHANGE WITH ENGINE

SPEED. AT IDLE THE LIGHTS

WILL DIM. AS THE ENGINE IS „„„

SPEEDED UP. THE LIGHTS

REMOVABLE

WILL BECOME THEIR BRIGHTEST. CONNECTIONS CONNECTIONS

WIRING INSULATED CUPS

INSULATED CLIPS WERE REMOVED FOR

SHOULD BE REPLACED TO

PROPERLY SECURE YOUR WIRING
