ASSEMBLY

CAUTION: DO NOT ASSEMBLE WITH
POWER RAKE PLUGGED INTO A
POWER SOURCE

STEP1:

(SEE FIGURE 1)

•

Turn the Power Rake housing upside down.

•

Fasten the end of the iower handie tube with air
intake hoies to the side of the Power Rake housing

with the iarge hoie. Use the right handie bracket (H),

hex boit (A), right handie ciamp (J) and wing knob
(D). Aiign the pin in the bracket with the siot in the
housing and tighten the wing knob.

STEP 3:

(SEE FIGURE 3)

• Turn the Power Rake housing upright and attach the

iong end of each of the middie handie tubes to the
iower handie tube using two carriage boits (C) and

wing knobs (D).

STEP 2:

(SEE FIGURE 2)

• Fasten the iower handie tube to the ieft side of the

Power Rake housing. Use the ieft handie bracket (I),

carriage boit (B), ieft handie ciamp (G) and wing knob

(D). Aiign the pin in the bracket with the siot in the
housing and tighten the wing knob

STEP 4:

(SEE FIGURE 4)

• Siide the power cord hoider (F) onto the right middie

handie tube.

Call 1 -866-576-8388 for missing parts or assembly help

DO NOT RETURN TO STORE
