SCHEMATIC

TRACTOR - - MODEL NUMBER 917.270860

BROWN

L-0J

HEADLIGHTS

IGNITION SWITCH

POSITION

CIRCUrr

■MAKE”

OFF

G + M + L

NONE

RUN/UGHT

B + L

A + Y

RUN

B + L

NONE

START

B + L + S

NONE

NOTE

YOUR TRACTOR IS
EQUIPPED WITH A SPECIAL

ALTERNATOR SYSTEM.
THE LIGHTS ARE NOT

CONNECTED TO THE

BATTERY, BUT HAVE THEIR

OWN ELECTRICAL SOURCE.

BECAUSE OF THIS, THE

BRIGHTNESS OF THE UGHTS

WILL CHANGE WITH ENGINE

SPEED. AT IDLE THE LIGHTS

WILL DIM. AS THE ENGINE IS

1^.1

“

SPEEDED UP, THE UGHTS

REMOVABLE

----- ---------------------------------------------------------------------- CONNECTIONS

orttucu ut', f Mfc UGHTS

NON-REMOVABLE

WILL BETOME THEIR BRIGHTEST. CONNECTIONS

WIRING INSULATED CUPS

NOTE: IF WIRING INSULATED CLIPS WERE REMOVED FOR

SERVICING OF UNIT, THEY SHOULD BE REPLACED TO

PROPERLY SECURE YOUR WIRING.
