SEARS CRAFTSMAN 9.0 H.P. SNOW THROWER MODEL 247,888530
Key.
No.
Part No. Description Key.
No.
Part No. Description
1. 618-0043 Dogg Assembly RH 30. 736-0169 Lock Washer
2. 618-0044 Dogg Assembly LH 32. 736-0351 Flat Washer
3. 618-0575 Shift Assembly: Steerable Drive 33. 736-0626 Flat Washer
4. 656-0012A Friction Wheel Disc Assy. 35. 737-0318 Grease
5. 684-0014B Shift Rod Assembly 36. 738-0924 Shoulder Screw
6. 684-0042C Bearing 37. 741-1111 Hex Flange Bearing
7. 784-5731B Transmission Frame 38. 741-04026 Hex Flange Bearing
8. 684-0131A Support Bracket Assembly 39. 741-0600 Ball Bearing
9. 710-0599 TT Screw 1/4-20 X 0.5" 40. 741-0701 Flange Bushing
10. 710-0809 TT Screw 1/4-20x1.25” 41. 746-0897 Auger Clutch Cable
11. 710-1652 TT Screw 1/4-20 X .625” 42. 746-0898B Drive Clutch Cable
12. 711-1267 Drive Shaft 43. 746-0956 Steering Cable
13. 711-1268 Actuator Shaft 44. 748-0190 Spacer
14. 711-1364 Pin 45. 750-1161A Support Tube; Axle
15. 712-0711 Jam Nut 3/8-24 Gr.8 46. 750-1162 Spacer
16. 712-3017 Hex Nut: 3/8-16 47. 756-0625 Roller Cable
17. 713-0233 Chain 48. 784-5590 Shift Bracket
18. 713-0374 Chain 49. 784-5687A Auger Clutch Cable Guide Bracket
19. 713-0413 Sprocket: 10T 50. 784-5689A Front Support Guide Bracket
20. 713-0472 Sprocket 51. 784-5730A Retaining Shaft: Actuator Drive RH
21. 714-0507 Cotter Pin 52. 784-5740 Retaining Shaft: Actuator Drive LH
22.
736-0142 Flat Washer 53. 784-5732 Frame Cover
23. 714-0474 Cotter Pin 54. 784-5733 Roller Bracket: Drive Cable
24.
25.
716-0102
721-0263
Snap Ring
Adhesive: Loctite™
55. 710-1233 Oval C-Sunk Machine Screw
26. 732-0209 Extension Spring 57. 725-0157 Cable Tie
27. 732-0264 Extension Spring 58. 746-0950 Turn Trigger
28.
29.
736-0105
736-0160
Bel! Washer
Flat Washer
59. 712-0703A Nut Insert
31
