REPAIR PARTS FOR MODEL 486.24839 40" SNOW THROWER
REF.
NO.
PART
NO.
QTY. DESCRIPTION REF.
NO.
PART
NO.
QTY. DESCRIPTION
1 63764 1 Lift Shaft Assembly 41 703-2735A 1 Bracket, Chute Crank
2 710-0865 2 Hex Bolt, 1/2-13x1" 42 720-0201A 1 Knob, Crank
3 710-0367 2 Hex Bolt, 5/8-11 X 1-1/4" 43 44917 1 Palnut, 3/8"
4 711-0332 2 Pin, Bracket Lift 44 43850 1 Pin, Roll 1/8" X 5/8"
5 712-0261 2 Nut, Hex Lock 5/8-11 Thread 45 63579 1 Assembly, Chute Crank Rod
6 43262 6 Nut. Hex Lock 1/2-13 46 784-5604 1 Handle, Chute Tilt
8 142 4 Pin, Cotter 1/8" X 3/4" 47 720-0232 1 Knob
9 43093 1 Pin, Cotter 1/8" x 1-1/2" 48 603-0302 1 Assembly, Chute Tilt Bracket
10 R19171616 6 Washer, 17/32" x1" 49 731-1313B 1 Guide, Cable
12 741-0192 2 Bearing, Flange With Flats 50 746-0928 1 Cable, Chute Control
13 783-0380 2 Link, 15.80" Long 51 746-0929 1 Cable, Chute Control with Clip
14 783-0381 2 Link, 11.75" Long 52 43064 3 Nut, Hex Lock 5/16-18
15 24476 2 Link, 4.88“ Long 53 43081 2 Washer, 5/16"
16 24311 1 Rod, Spacer 54 24285 1 Plate, Mounting (LH.)
17 47599 2 Hex Bolt, 5/16-18 X 1“ (Locking) 55 24284 1 Plate, Mounting (R.H.)
18 43086 16 Lock Washer, 5/16" 56 47093 1 Keg, Plastic
19 24298 1 Bracket, Lift 57 23812 2 Brace, Side (Weight Tray)
20 683-0130 1 Assembly, Handle Lift Bracket 58 24288 1 Brace, Cross (Weight Tray)
21 747-3248A 1 Rod, Index Lift 59 24289 1 Tray. Weight
22 47277 1 Screw, Hex Slotted #10 60 47631 4 Hex Bolt, 3/8-16x1" Self Tap
23 732-0306 1 Spring, Compression 61 43003 6 Lock Washer, 3/8"
24 R19131316 1 Washer, 13/32" x 13/16" 62 43082 4 Nut, Hex Lock 3/8-16
25 736-0400 1 Washer, .218“ x .62" 63 43083 10 Nut, Hex 5/16-18
26 43080 1 Carriage Bolt, 5/16-18 x 3/4" 64 43084 2 Hex Bolt, 5/16-18x1-3/4"
27 43182 2 Hex Bolt, 5/16-18x3/4" 65 44326 4 Carriage Bolt, 5/16-18 x 1"
28 R19111116 2 Washer, 11/32 x 11/16 x 3/64 66 43351 1 Hex Bolt, 1/2-13x1-1/4"
29 47338 1 Pin, Spring 1/4" X 1-1/2" 67 43353 1 Lock Washer, 1/2"
30 46954 1 Pin, Attachment 68 43682 2 Carriage Bolt, 5/16-18 x 1-1/4"
31 43343 1 Pin, Haircotter#4 (1/8") 69 43790 1 Strap, Tarp 25" Long
32 24654 1 Plate, Side (R.H.) 70 44215 2 Carriage Bolt, 5/16-18 x 1-3/4"
33 24653 1 Plate, Side (L.H.) 71 44695 2 Washer, Bowed
34 47326 1 Tube, Lift Handle 72 712-0206 1 Nut, Hex 1/2-13
35 47555 1 Cable, Lift 73 738-0234 2 Bolt, Shoulder
36 712-0127 1 Nut, Flat Weld #10-24 74 726-0178 3 Tie, Nylon
37 710-1233 1 Screw, Oval #10-24x1" 75 63755 1 Assembly, Cable Release Trigger
38 46446 1 Grip, Handle 76 47317 1 Plastic Cap
39 47027 1 Tube, Crank Rod Support 77 43601 1 Washer, 1.59" x 1.032" x .060"
40 741-0475 2 Bushing, 3/8" Plastic 78 47336 1 Pin, Spring 5/32" x 1-1/2"
79 47361 2 Slotted Truss Hd. Bolt, 3/8-16 x 1"
80 47554 1 Housing, Trigger
81 R19172410 2 Washer, 1/2"
25
