TRACTOR - - MODEL NUMBER 917.273840

SCHEMATIC

POSITIONCIRCUIT “MAKE”

OFF

M-t-G+AI

NONE

RON/LIGHT

B+A1

A2‘fL

RUN

B+A1

NONE

START

B + S + A1

NONE

WIRING INSULATED CLIPS

NOTE:

IF WIRING INSULATED CLIPS WERE REMOVED FOR

SERVICING OF UNIT, THEY SHOULD BE REPLACED TO
PROPERLY SECURE YOUR WIRING.
