Craftsman 486.24276 - Manual (Page 11)

REPAIR PARTS FOR MODEL 486.24276 SNOW CAB
REF.
NO.
PART
NO.
QTY. DESCRIPTION REF.
NO.
PART
NO.
QTY. DESCRIPTION
1 49242 1 Top Base leg tube 15 25795 1 Front Brace Rod
2 25014 2 Upright Tube 16 49325 2 Base Leg Tube
3 25013 2 Top Tube 17 40003 1 Base Leg Tube, Flattened
4 25012 1 U-Tube 18 25302 1 Right Base Bracket
5 25015 3 Support Rod 19 25303 1 Left Base Bracket
6 48738 1 Vinyl Canopy 20 25835 1 Right Support Bracket
7 23658 4 Spacer 21 25794 1 Left Support Bracket
8 43720 2 Plastic Knob 22 25793 1 Base Bracket
9 44977 6 Carriage Bolt, 5/16-18 x 2" 23 46594 4 Carriage Bolt, 5/16-18 x 2-3/4"
10 43081 4 Flat Washer, 5/16" 24 44180 1 Hex Bolt, 5/16-18x2"
11 43648 4 Hex Bolt, 1/4-20 X 1-1/2" 25 43176 1 Carriage Bolt, 1/4-20 x 1"
12 47189 5 NylockNut, 1/4-20 26 47810 5 NylockNut, 5/16-18
13 48661 4 Adhesive Pad 49952 1 Owner's Manual
14 43063 2 Hex Bolt, 5/16-18 X 1"
11
