Index to parts and controls
Refer to the pages indicated in parentheses () for details.
Front panel
SLV-N88/SLV-N77
SLV-N55
A 1/1 POWER switch (43) (45)
B Remote sensor (7)
C Tape compartment
D A EJECThutton(31)
E m REW (rewind) hutton (31) (48)
F H PLAY hutton* 1 (31)
G FF (fast-forward) hutton (31) (48)
H • REC (record) hutton (34) (50) (59)
>
a
a
o'
3
w
5"
o
3
&>
o'
3
I ■ STOP hutton* 1 (31) (59)
J X PAUSE hutton (31) (59)
K dial TIMER*2 (36)
L CHANNEL/TRACKING +/- huttons* 3
(34) (56)
M line -2 in VIDEO/AUDIO L/Rjacks
(58)
*' The \H PLAY and ■ STOP huttons have a
tactile dot (SLV-N88 and SLV-N77 only).
* 2 SLV-N88 only
* 3 The channel + hutton has a tactile dot.
