SERVICE MANUAL
US Model
Canadian Model
CDP-608ESD
AEP Model
UK Model
E Model
CDP-338ESD
This photo is CDP-338ESD
SPECIFICATIONS
Compact disc player
Frequency
response
2 Hz - 20 kHz ± 0.5 dB (CDP-338ESD)
2 Hz - 20 kHz ± 0.3 dB (CDP-608ESD)
Signal to noise ratio More than 113 dB
Dynamic range
More than 100 dB
Harmonic distortion Less than
0.0022%
Channel separation
More than 110 dB
Outputs
LINE OUT (FIXED)
(phono jacks)
LINE OUT (VARIABLE)
(phono jacks)
DIGITAL OUT
(COAXIAL)
(cable)
DIGITAL OUT (OPTICAL)
(optical output connector)
HEADPHONES
(stereo phone jack)
Output level 2 V (at 50 kiloohms)
Load impedance over 10 kiloohms
Output level max. 2 V (at 50 kiloohms)
Load impedance over 50 kiloohms
Output level max. 0.5 Vp-p
Load impedance 75 ohms
Model Name Using Similar Mechanism
New
CD Transport Mechanism Type
KSS-151A
Optical Pick-Up Block Type
BU-6B
General
Wave length 660 nm
Output level — 18 dBm
Output level max. 28 mW
Load impedance 32 ohms
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK OR DOTTED
LINE WITH MARK ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB
LISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM
POSANTS QUE PAR DES PIECES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
Power
requirements
Power
consumption
Dimensions
(approx., including
projections)
Weight (approx.)
AEP Model:
(CDP-338ESD)
220 V AC (or 240 V AC adjustable by
Sony personnel), 50/60 Hz
UK Model;
(CDP-338ESD)
240 V AC (or 220 V AC adjustable by
Sony personnel), 50/60 Hz
US, Canadian Model:
(CDP-608ESD)
120 VAC, 60Hz
E Model:
(CDP-338ESD)
110,120, 220 or 240 V AC adjustable,
50/60 Hz
27 W
470X125X375 mm
(w/h/d)
(18V
b
X5X147*
inches)
12.5 kg (27 lbs 11 oz)
continued on next page —
COMPACT DISC PLAYER
