Craftsman 486.244122 - Manual (Page 3)

3
A
C
M
N
O
P
Q
R
S
T
U
L
K
D E F G H I J
B
W X Z AA
GG
DD CC EE
HH
BB FF
NOT SHOWN FULL SIZE
SHOWN FULL SIZE
II
Y
JJ KK
V
REF. QTY. DESCRIPTION REF. QTY. DESCRIPTION
CONTENTS OF PARTS PACKAGE
A 1 Hex Bolt, 1/2" x 4"
B 2 Hex Bolt, 1/2" x 2-3/4"
C 9 Hex Bolt, 3/8" x 1-1/4"
D 1 Hex Bolt, 3/8" x 1"
E 1 Hex Bolt, 5/16" x 1-1/2"
F 1 Hex Bolt, 1/4" x 1-1/2"
G 1 Hex Bolt, 1/4" x 3/4"
H 2 Hex Bolt, 3/8" x 1" Thread Forming
I 1 Shoulder Bolt, (Special) 3/8" x 5/8"
J 2 Carriage Bolt, 3/8" x 1-1/4"
K 4 Flat Washer, 7/16" Std.
L 1 Flat Washer, 3/8" Std.
M 4 Lock Washer, 3/8"
N 2 Nylock Nut, 1/2"
O 2 Hex Jam Nut, 1/2"
P4 Hex Jam Nut, 7/16"
Q 1 Whizlock Nut, 3/8"
R 10 NyLock Nut, 3/8"
S 2 Hex Jam Nut, 3/8"
T 1 Nyock Nut, 5/16"
U 4 Hex Jam Nut, 5/16"
V 3 Nyock Nut, 1/4"
W 2 Keeper Plate
X 1 Lift Arm Link
Y 1 Stop Angle
Z 1 Cable Mount Bracket
AA 2 Cable End Fitting
BB 1 Handle Guide
CC 4 Clevis Pin, 3/8" x 3/4"
DD 6 Hairpin Cotter, 3/32"
EE 10 Hairpin Cotter, 1/8"
FF 1 Spring Pin, 1/4" x 1"
GG 1 Nylon Tie
HH 1 Spring, Angle Lock
II 9 Spacer, Short
JJ 1 Spacer, Long
KK 2 Trunnion, Lift Rod
