Terminal cover

Remote sensor
(p. 24)

Stereo microphone
(p. 69)

Tripod socket (p. 36)

OPEN/EJECT switch (p. 22)

S-video IN/OUT terminal (p. 40)

DV IN/OUT terminal
(p. 89)

USB terminal
(p. 122, 135)

MIC terminal (p. 69)

Bottom view

AV IN/OUT terminal
(p. 40) / (phones)
terminal (p. 39, 70)

DC IN terminal (p. 15)

CHARGE indicator
(p. 16)

Assist lamp
(White LED)
(p. 57)
