LaView 4 Channel 2 Camera - Manual

960H
2
2
2
Plug each split end to a siamese power cable connected to the
camera. Repeat step for all cameras.
Premade
Siamese
Cable
DC 12V Adapter
Camera
Splitter
Your DVR will automatically choose your BNC out as primary
output device if BNC is connected pre-boot up.
Connect the last splitter cable into the power 12VDC adapter
and connect the other end on the rear panel of the DVR.
Connect the mouse cable to the Mouse USB port in the
real panel of DVR.
Switch the ON button to boot up your DVR.
Select and follow the steps in your on screen start up wizard
View remotely for Free! Download your mobile app for
Smartphones, tablets, Macs, and PCs.
Visit us at
www.laviewsecurity.com
FREE APP
SCAN ME!
FREE APP
SCAN ME!
4
the DVR, the main menu will then appear. The digital video
recorder system is now set up.
Connect your HDMI or VGA to your DVR.
Innovation That Secures
Adapter
