Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids
Main Frame
continued…..
Angle Adjustable Footboard…….
5. To change the height of the footboard on
the frame, loosen the 2 hex head screws
on the footboard frame clamps. Set the
desired height and tighten.
Warning: In all footplate and hanger adjust-
ments, be sure that all screws are tightened
securely for your safety.
Quick Release Axle*
The Freedom 2/Freedom 2 Kids is equipped
with double lock quick release axles that
release with the push of a button. This double
lock quick release mechanism allows the rear
wheels to be easily removed for transportation
or storage.
To remove the rear wheel:
1. Unlock the wheel lock.
2. Grasp the frame with one hand.
3. With the other hand, squeeze the quick
release button.
4. The wheel will then pull off easily.
Warning: the axle is not properly locked until
the outside quick release button pops out to its
full extended position.
The lowest point of the footrest plate should be
at least 2 1/2” from the ground to ensure the
proper clearance.
*Patented
