3 4/8/04 Application Systems Hydraulic Meterflow Pump 507-097M
Great Plains Mfg., Inc.
Assembly
507-059A PUMP 3-POINT METERFLOW HYD ASSY
Your Kit Includes:
1 507-013L PUMP METERFLOW - HYDRAULIC
1 507-029D 3-PT SPRAYER PUMP BRACKET
1 507-097M 3P/AS HYD PUMP ASSY MANUAL
2 800-123C CLAMP WRM DRV #16 SS (.68-1.5)
2 800-124C CLAMP WRM DRV #24 SS (1.06-2)
1 800-303C CABLE TIE 2 DIA MIN - BLK
2 802-079C HHCS 3/8-16X1 1/4 GR5
6 803-068C NUT HEX FLANGE 3/8-16 PLT
2 806-021C U-BOLT 3/8-16 X 3 1/32 X 4
1 810-247C VALVE, HYD PUMP CHECK
2 811-394C CP 3/4FORB MALE QD
2 811-500C HH1/2R2 050 3/4MORB 3/4MORB90
1 817-348C PLASTIC HOSE LABEL
1 830-092C AD 1 1/4MNPT X 1 1/2HB POLYP
1 990-079R HOSE 1 1/2ID EPDM SUCTION HOSE
1.25 990-082R HOSE 1 ID 200PSI EPDM
Qty. Part No. Part Description
1 507-013L PUMP METERFLOW - HYDRAULIC
2 800-123C CLAMP WRM DRV #16 SS (.68-1
2 800-125C CLAMP WRM DRV#28 SS(1.31-2.
1 800-303C CABLE TIE 2 DIA MIN - BLK
2 802-022C HHCS 3/8-16X1 1/2 GR5
2 803-068C NUT HEX FLANGE 3/8-16 PLT
1 810-247C VALVE, HYD PUMP CHECK
2 811-160C HH1/2R1 050 3/4MORB
2 811-394C CP 3/4FORB MALE QD
1 817-348C PLASTIC HOSE LABEL
1 830-092C AD 1 1/4MNPT X 1 1/2HB POLY
4.667 990-079R HOSE 1 1/2ID EPDM SUCTION H
2.500 990-082R HOSE 1 ID 200PSI EPDM
Qty. Part No. Part Description
507-007A PUMP TA HYDRAULIC METERFLOW ASSY
Your Kit Includes:
