3 Hydraulic Remote Great Plains Manufacturing, Inc.
586-541M 04/09/2013
Hydraulic Remote Leveling Decal
Note: Close cylinder before installing 858-059C level de-
cal . Clean surface of the top of 589-487H level in-
dicator .
Refer to Figure 2
15. With cylinder
in the closed position, remove back-
ing and align the G on the 858-059C level decal
with the pointer of the 589-487H level indicator
.
Center the decal side to side and press the decal
firmly on top of the 589-487H level indicator
being
careful not to cause air bubbles under decal.
Note: The machine should be run level from front to rear in
the field at all times. Never run machine deeper on
front or rear or this will cause poor field performance.
FigureSpacer:
FigureSpacer:
Null4:
Figure 3
Hydraulic Remote Leveling Decal
43122
3
2
1
4
1
3
2
1
3
4
2
