Kino Flo Foto-Flo 44 - Manual (Page 6)

4
2
2
4
Each switch controls two lamps as illustrated.
Fuse provides circuit protection. If the Fuse
is blown or open replace it with the same
type of fuse rating as marked.
Cold Temperature Operation
The Foto-Flo 44 is designed to operate at temperatures from 14F to 122F
(–10C to +50C). In cold temperatures, the electronic ballast may not strike the
lamps instantly. Switch the Fixture to OFF, wait seven seconds and try again. If
the ballast does not strike after two or three attempts, turn off the Fixture,
check that the Lamp connections are secure and correctly color code matched
and re-strike. Once operating for a few minutes, the Lamps should re-str
instantl
,
ike
y.
6
MTP-L Lollipop 3/8” Pin
MTP-LBS Lollipop w/ Baby Receiver short
DFS-4804 Foto-Flo 44 Flozier, Full
DFS-4804-H Foto-Flo 44 Flozier, Half
