Classic Series
F127-31 (Globe)
F1127-31 (Angle)
Installation Guidelines
• Prior to installation, flush line to remove debris.
• Install valve horizontally “in line” (cover facing UP), so flow arrow matches flow through the line. Avoid
installing valve 6” and larger vertically. Consult factory prior to ordering if installation is other than
described.
• Install inlet and outlet isolation valves. NOTE: When using butterfly valves, insure disc does not
contact control valve. Damage or improper valve seating may occur.
• Provide adequate clearance for valve servicing and maintenance.
• Install pressure gauges to monitor valve inlet, outlet, and static head pressure.
• Provide adequate drain for cover chamber discharge if “wet drain” option is selected. Consult “Valve
Cover Capacity” chart on appropriate main valve Engineering Bulletin.
• Install static tank head sense line. For optimum control, sense line should be: 1) Installed with
an upward angle (towards reservoir) to avoid air accumulation, 2) Connected no further than forty-five
pipe diameters from the reservoir, and 3) A minimum of 1/2” diameter.
• Connect Solenoid Pilot to appropriate power source in compliance with local electrical codes.
Other Watts ACV Altitude Control Valves
F127-1 / F1127-1 One Way Flow Altitude Valve
F127-2 / F1127-2 Two Way Flow Altitude Valve
F127-8 / F1127-8 One Way Flow Altitude Valve with Pressure Sustaining Feature
F127-11 / F1127-11 One Way Flow Altitude Valve with Delayed Opening Feature
F127-32 / F1127-32 One Way Flow Altitude Valve with Solenoid Override Feature
TWO-WAY FLOW ALTITUDE VALVE
with SOLENOID OVERRIDE
FEATURE
