TOURnado™ IP COB User Manual Rev. A © Copyright 2014 Blizzard Lighting, LLC
Dimming Mode
Each allows for different amounts of steps for much smoother (and slower) dimming capabilities.
1.) Navigate the menu using the buttons until you reach nodE.
2.) Push the button.
3.) Use the buttons to select nod0-nod4.
4.) Press the button to confirm.
DMX Values In-Depth (8-Channel Mode)
Channel Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red Intensity (0% <--> 100%)
3 000 <--> 255 Green Intensity (0% <--> 100%)
4 000 <--> 255 Blue Intensity (0% <--> 100%)
5
000 <--> 010
011 <--> 255
Strobe
No Function
Strobe (Slow <--> Fast)
6
000 <--> 015
016 <--> 044
045 <--> 074
075 <--> 104
105 <--> 134
135 <--> 164
165 <--> 194
195 <--> 224
225 <--> 255
Static Colors + Auto Mode
Dimming
Red
Green
Blue
Red+Green
Red+Blue
Green+Blue
Red+Green+Blue
Auto Run (Slow <--> Fast)
7
000 <--> 015
016 <--> 255
Auto Mode
No Function
Color Jump (Slow <--> Fast)
8
000 <--> 005
006 <--> 055
056 <--> 105
106 <--> 155
156 <--> 205
206 <--> 255
32-Bit Dimmer
As set in the control menu display
Mode 0 = 8-bit, 256 dimming steps
Mode 1 = 32-bit, 0-25% intensity range
Mode 2 = 32-bit, 0-50% intensity range
Mode 3 = 32-bit, 0-75% intensity range
Mode 4 = 32-bit, full intensity dimming
DMX Values In-Depth (5-Channel Mode)
Channel Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red Intensity (0% <--> 100%)
3 000 <--> 255 Green Intensity (0% <--> 100%)
4 000 <--> 255 Blue Intensity (0% <--> 100%)
6
000 <--> 010
011 <--> 255
Strobe
Strobe Off
Strobe (Slow <--> Fast)
