Torrent F5™ Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
2. MEET THE TORRENT F5™ SPOT
CONTROL FEATURES
• r e s U DMX Personalities, 14/16-channel DMX LED moving yoke
• Pan: 540º/630º/ Tilt: 270º
• Color wheel: 7 colors + white, rainbow color spin at variable speeds
• 7 interchangeable, rotating slot-n-lock gobos + open (4 glass installed)
• 9 static gobos (Gobo Wheel #2)
• Ability to layer gobos for multicolor/multi-textured effects.
• Gobo wheel spin at variable speeds
• Gobo indexing
• 3-facet & 5-facet “3D Effect” rotating prism
• Frost
• Variable 3-mode electronic strobe
• Variable electronic dimmer (0 – 100%)
• Remote focus via DMX
• Variable mechanical iris with burst and linear control
• Remote reset
• Multiple built-in automated & sound activated programs
• User-programmable built-in programs
ADDITIONAL FEATURES
• Lux: 61,600 @ 1m, 15,100 @ 2m
• Beam Angle: 15º
• Light source: 150W White LED, 6,500K, 50,000 hrs
• Ultra-fast 3-phase pan/tilt motors
• POWERCON Power Input/Output connections
• Quarter-Turn “Omega” type clamp brackets
• Motor calibration utility on-board
DMX Quick Reference
Channel 16-Bit Mode 8-Bit Mode Design Mode (Default)
1 Pan Pan Shutter
2 Pan Fine (16-Bit) Tilt Dimmer
3 Tilt Color Color
4 Tilt Fine (16-Bit) Gobo Wheel #1 Gobo Wheel #1
5 Color Gobo Rotation Gobo Rotation
6 Gobo Wheel #1 Gobo Wheel #2 Gobo Wheel #2
7 Gobo Rotation Shutter/Strobe Iris
8 Gobo Wheel #2 Dimmer Focus
9 Shutter/Strobe Focus Prism/Frost
10 Dimmer Prism/Frost Prism Rotation
11 Focus Prism Rotation Pan
12 Prism/Frost Iris Tilt
13 Prism Rotation Pan/Tilt Speed Pan/Tilt Speed
14 Iris Reset/Special Functions Reset/Special Functions
15 Pan/Tilt Speed N/A N/A
16 Reset/Special Functions N/A N/A
