The Puck Q6: Unplugged Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
Using The Battery System
The Puck Q6 Unplugged™ features our proprietary intelion™ Lithium-
Ion internal battery system which allows the user to the flexibility to
operate their light fixture without AC power for up to 20 hours.
The battery system’s built-in microprocessor controls charging and
overall battery health, so all you need to do is plug and play. A charge
indicator on the back of the fixture turns from RED to GREEN when
charging is complete.
IMPORTANT:
A full charge is obtained after charging the fixture for at least 4 hours.
The fixture will automatically stop charging when the battery is in opti-
mal condition.
Display color/fade/chase, strobe, wiCICLE operation, and environmen-
tal factors including ambient temperature will all impact battery life.
Depending on program, battery life may range from 3 to 20 hours.
*Runtime & luminous intensity testing data for Amber (Q6A): TBA
Puck Q6W Unplugged Runtime/Luminous Intensity Testing:
Approx. maximum run times with full charge, at 68F (20C):
Time 1m 2m 1m 2m 1m 2m 1m 2m 1m 2m
0:00 7630 2350
0:30 7200 2140 2000 650 1650 480 2500 750 1900 560
1:00 7200 2140 2000 650 1650 480 2500 768 1900 560
1:30 7200 2140 2000 650 1650 462 2430 760 1900 540
2:00 7080 2140 1800 650 1650 473 2260 777 1760 560
2:30 7000 2110 1960 630 1620 473 2420 760 1880 550
3:00 7000 2140 1950 630 1650 480 2440 770 1850 540
3:30 7000 2110 1960 630 1620 473 2420 760 1880 550
4:00 7000 2140 1950 630 1650 480 2440 770 1850 540
4:30 7000 2140 1950 630 1650 480 2440 770 1850 540
5:00 7000 2140 1950 630 1650 480 2440 770 1850 540
Red Green All Blue White
Color Preset Color Name Run Time
Col 1 Red 22.25 Hours
Col 2 Green 11.5 Hours
Col 3 Blue 8 Hours
Col 4 Yellow / R+G 8.25 Hours
Col 5 Cyan / G+B 5 Hours
Col 6 Magenta / R+B 7.75 Hours
Col 7 White / R+G+B 5 Hours
