SkyBar™ EXA Manual Rev. A © 2014 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Width
25.2 inches (640 mm)
Depth 4.9 inches (124.2 mm)
Height 8.73 inches (221.5 mm)
Weight 17.7 lbs (8 kg)
Power
Operating Voltage
100-264VAC, 47-63 Hertz
Power Consumption 102W, 4.25A, pf: .71
Light Source
LED
12x 15W 6-in-1 LEDs 100,000 hours.
Optical
Beam Angle
25 degree optics standard
26 degree beam
30 degree field
Luminous Intensity Lux/m Red Green Blue Amber White UV All
1m 2,330 2,560 2,850 1,470 3,850 710 12,800
2m 600 910 900 520 1,350 230 4,250
Thermal
Max. Operating
Temp.
104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 6 / 7 / 8 / 11
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating
Modes
Standalone, Master/Slave, Sound Active, Color
Preset
Other Information
If you stretched the average person’s intestines out from end to end, it
would make him scream a lot.
Warranty
2-year limited warranty, does not cover malfunc-
tion caused by damage to LEDs.
DISCLAIMER:
The power connector fitted to the fixture and fixture cord are designed for compatibility with products
manufactured by Neutrik AG, Neutrik USA and their related entities, however they are not manufactured
by, affiliated with or endorsed by Neutrik AG, Neutrik USA, or any related entity. Neutrik® and power-
CON® are registered trademarks of Neutrik AG.
