RockLite™ Fab5 Manual Rev. A © 2013 Blizzard Lighting, LLC
2. MEET THE ROCkLITE FAB5™ LED PAR
CONTROL FEATURES
• Light Source: 18* 15-watt, 5-in-1 RGBWA All-In-One LED’s
• Variable electronic strobe
• Variable electronic dimmer
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• Built-in sound active programs
• RGBAW color mixing ability in standalone mode
ADDITIONAL FEATURES
• Rugged and well-built (It hits the gym regularly)
• 4-Button LED control panel for easy programming
• Flicker-free constant-current LED driver
• Dual mounting brackets for positioning flexibility
DMX Quick Reference - 10/9 Channel Mode
Channel What It Does (10 Ch.) What It Does (9 Ch.)
1 Dimmer Dimmer
2 Red Intensity Red Intensity
3 Green Intensity Green Intensity
4 Blue Intensity Blue Intensity
5 Amber Intensity Amber Intensity
6 White Intensity White Intensity
7 Strobe Strobe
8 Built-in Programs Built-in Programs
9 Speed Adjustment Speed Adjustment
10 32-Bit Dimmer ---
DMX Quick Reference - 4/5 Channel Mode
Channel What It Does (5 Ch.) What It Does (4 Ch.)
1 Red Intensity RGB Color Mixing
2 Green Intensity Amber Intensity
3 Blue Intensity White Intensity
4 Amber Intensity Dimmer (0-100%)
5 White Intensity ---
