PixelStorm™ 240 Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
DMX Values In-Depth (10-Channel Mode, 2-Segments)
Segment 1
Channel 1 - Red
Channel 2 - Green
Channel 3 - Blue
Segment 2
Channel 4 - Red
Channel 5 - Green
Channel 6 - Blue
In 10-channel mode, the fixture is divided into 2 segments as illustrated in the table
above. Channel groups 1-3 and 4-6 control the R/G/B values of each segment, respec-
tively (0 <--> 100%).
Channels 7,8,9, and 10 have the same values as 7-channel mode, channels 4-7.
See 7-channel mode table on page 13.
DMX Values In-Depth (16-Channel Mode, 4-Segments)
SEGMENT 1
Channel 1 - Red
Channel 2 - Green
Channel 3 - Blue
SEGMENT 2
Channel 4 - Red
Channel 5 - Green
Channel 6 - Blue
SEGMENT 3
Channel 7 - Red
Channel 8 - Green
Channel 9 - Blue
SEGMENT 4
Channel 10 - Red
Channel 11 - Green
Channel 12 - Blue
In 16-channel mode, the fixture is divided into 4 segments as illustrated in the table
above. Channel groups 1-3, 4-6, 7-9, and 10-12 control the R/G/B values of each seg-
ment, respectively (0 <--> 100%).
Channels 13,14,15, and 16 have the same values as 7-channel mode, channels
4-7. See 7-channel mode on page 13.
DMX Values In-Depth (24-Channel Mode, 8-Segments)
SEGMENT 1
Ch 1 - Red
Ch 2 - Green
Ch 3 - Blue
SEGMENT 2
Ch 4 - Red
Ch 5 - Green
Ch 6 - Blue
SEGMENT 3
Ch 7 - Red
Ch 8 - Green
Ch 9 - Blue
SEGMENT 4
Ch 10 - Red
Ch 11 - Green
Ch 12 - Blue
SEGMENT 5
Ch 13 - Red
Ch 14 - Green
Ch 15 - Blue
SEGMENT 6
Ch 16 - Red
Ch 17 - Green
Ch 18 - Blue
SEGMENT 7
Ch 19 - Red
Ch 20 - Green
Ch 21 - Blue
SEGMENT 8
Ch 22 - Red
Ch 23 - Green
Ch 24 - Blue
In 24-channel mode, the fixture is divided into 8 segments as illustrated in the table
above. Channel groups 1-3, 4-6, 7-9, 10-12, 13-15, 16-18, 19-21, and 22-24 control the
R/G/B values of each segment, respectively (0 <--> 100%).
DMX Values In-Depth (28-Channel Mode, 8-Segments)
SEGMENT 1
Ch 1 - Red
Ch 2 - Green
Ch 3 - Blue
SEGMENT 2
Ch 4 - Red
Ch 5 - Green
Ch 6 - Blue
SEGMENT 3
Ch 7 - Red
Ch 8 - Green
Ch 9 - Blue
SEGMENT 4
Ch 10 - Red
Ch 11 - Green
Ch 12 - Blue
SEGMENT 5
Ch 13 - Red
Ch 14 - Green
Ch 15 - Blue
SEGMENT 6
Ch 16 - Red
Ch 17 - Green
Ch 18 - Blue
SEGMENT 7
Ch 19 - Red
Ch 20 - Green
Ch 21 - Blue
SEGMENT 8
Ch 22 - Red
Ch 23 - Green
Ch 24 - Blue
In 28-channel mode, the fixture is also divided into 8 segments as illustrated in the table
above. Channel groups 1-3, 4-6, 7-9, 10-12. 13-15, 16-18, 19-21, and 22-24 control the
R/G/B values of each segment, respectively (0 <--> 100%).
Channels 25,26,27, and 28 have the same values as 7-channel mode, channels
4-7. See 7-channel mode on page 13.
