Autocue SSP17 V2 - Manual

SSP17
Guide
Camera Fixing
16. Fix the camera in
place using the camera
screws provided.
1/4” BSW
17. Connect the power
supply and the VGA or
video cable.
Power Supply
autocue.com
12. For smaller cameras the camera plate will need
to be raised. Remove the four thumb screws and then
lift off the plate.
13. Install four camera plate pillars
of the appropriate height.
14 Re-fix the camera
plate using the four
screws provided.
15. To achieve the maximum
height, combine the long and
short pillars.
Pillar combinations
3/8” BSW
11. For larger cameras the mounting plate may need
extending. Loosen the four thumb screws on the
camera plate and remove the rear two, the plate will
now slide out. Replace the two rear screws and
tighten them to secure the plate.
