7 AJA FiDO-Series SDI/Optical Fiber Converters, User Manual — Specifications
Specifications
Item Specification
Formats 3Gb, 1.5Gb, 270Mb, Auto Select
Video Inputs/Outputs SDI (SMPTE 259/292/296/424), 2x BNC
I x Single mode optical fiber:
LC connector (FiDO-R, FiDO-T)
SC connector (FiDO-R-SC, FiDO-T-SC)
ST connector (FiDO-R-ST, FiDO-T-ST)
2x Single mode optical fiber:
LC connectors (FiDO-2R, FiDO-2T, FiDO-TR)
Cable Equalization (BNC inputs,
1694 coax) 270mb, 400m
1.5Gb, 200m
3Gb, 140m
Input/Output Return Loss (BNC) >15db, 270Mb - 3Gb
Optical Outputs Wavelength: 1310 nm
Output Power: -2dBm typical
Size 4.6" x 1.71 " x.85" (117 x 43.5 x 21.6mm)
Power +5-20 VDC
1.5 watts (FiDO-T, FiDO-R, FiDO-T-SC, FiDO-R-SC,
FiDO-T-ST, and FiDO-R-ST)
2.5 watts (FiDO-2R, FiDO-2T, and FiDO-TR)
Requires Power Supply
(AJA power supply model DWP or DWP-U recommended)
