Operating features – Wood’s Powr-Grip FLEX5HV11AC User Manual
Page 7
Rev 9.0/9-13
5
FLEX-HV11AC: #35032
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard FLEX2HV11AC shown.
1 LIFT SPOOL
5 VACUUM PAD
9 POWER SWITCH
2 CONTROL HANDLE
6 VACUUM RESERVE TANK
10 VACUUM LIFT LIGHT
3 MOVABLE PAD MOUNT
7 AIR FILTER
11 VACUUM GAUGE
4 PAD FRAME
8 Enclosure with
12 VACUUM CONTROL VALVE
VACUUM SWITCH
13 VACUUM PUMP
