SPECIFICATIONS
Model Number: 6 Vacuum Pads 8 Vacuum Pads
Vertical Configuration: PFV69AC --
Horizontal / Small Configuration: PFHS69AC PFHS89AC
Horizontal / Large Configuration: PFHL69AC PFHL89AC
Maximum Pad Spread: (to outer edges)
Vertical Configuration: 57¼" x 46¼" [1451 x 1172 mm] --
Horizontal / Small Configuration: 37¼" x 46¼" [943 x 1172 mm] 39¼" x 47¼" [994 x 1197 mm]
Horizontal / Large Configuration: 46¼" x 57¼" [1172 x 1451 mm] 39¼" x 59¼" [994 x 1502 mm]
Lifter Weight: (for larger configurations) 110 lbs [50 kg] 135 lbs [61 kg]
Load Capacity: (rated at 16" Hg [-54 kPa] on clean, smooth, nonporous flat surfaces 1 )
Per-Pad: 125 lbs [56.5 kg] 125 lbs [57 kg]
Maximum: 700 lbs [320 kg] 1000 lbs [455 kg]
Description: Designed for use with a crane or other hoisting equipment, PF-9AC lifters employ
vacuum to hold a load for lifting, and they provide manual 180° rotation and manual
90° tilt movements for load manipulation.
Power Source: See serial number plate for specific AC voltage, frequency and amperage.
Vacuum Pads: 9" [23 cm] nominal diameter (Model VPFS9), standard rubber, spring-mounted (¼" [7
mm] travel), with #60 filter screen
Rotation Capability: Manual, 180°, with automatic locking at each ¼ revolution (when desired)
Tilt Capability: Manual, 90°, with automatic locking in vertical position
Vacuum Pump: Rotary vane type, 2.5 SCFM [71 liters/minute] nominal airflow
Vacuum Reserve Tank: Vacuum reservoir helps prevent immediate vacuum loss in case of power failure.
Vacuum Gauge: Dial gauge indicates current vacuum level in positive inches of Hg and negative kPa.
Options: See separate instructions about optional features.
Operating Elevation: Maximum = 8000 feet [2438 meters]
Operating Temperatures: 32° to 104° F [0° to 40° C]
Service Life: This lifter is designed to have a service life of at least 20,000 lifting cycles, when used
and maintained as intended. Vacuum pads, filter elements and other wear-out items
are excluded; see MAINTENANCE and REPLACEMENT PARTS LIST for more information.
For the D ISPOSAL OF THE L IFTER after its service life, see INTENDED USE.
ASME Standard BTH-1: Design Category "B", Service Class "0" (see www.powrgrip.com for more information)
!!-CE-!! Note: This symbol appears in the INSTRUCTIONS manual only when requirements of a CE Standard are
different from requirements of other standards that also apply to this vacuum lifter. CE requirements are mandatory
in geographical areas where CE Standards apply, but may be optional in other locations.
1
Load Capacity is based on a friction coefficient of 1; see MAINTENANCE: V ACUUM P AD M AINTENANCE : Friction Coefficient for
additional information.
