Paxton CARDLOCK reader User Manual
Paxton
Ins-30017 CARDLOCK reader
18/07/2011
Technical Support
Technical help is available: Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
01273 811011
Fitting
Readers mounted together
Mounted on metal surface
Suitability
Security-sensitive doors
Wet environments
Cable extensions
Readers can be extended using Belden CR9540 10-core overall screened cable to a maximum of 100 metres.
Reader covers
A black plastic or satin chrome cover comes supplied with the reader.
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
