0 typical test workflow, Typical test workflow – MTS Multipurpose Express User Manual
Page 16
Description
Panel
Callout
Start/stop test procedure button and display of test
procedure status.
Test Run
5
List of resource validation and other errors.
Error List
6
List of application and test run errors.
Application/Test Run Logs
7
3.4.0 Typical Test WorkFlow
The following tasks make up a typical test workflow.
1. Prepare the Test Station
a)
Starting Station Manager and Loading Station Configuration
on page 18.
b)
Starting MPX and Applying Hydraulic Power
on page 19.
2. Install a Specimen
a)
Setting Station Limits in Station Manager Application
on page 20.
b)
Positioning Actuator and Installing Specimen
on page 21.
c)
Applying Offsets to the Input Signal—Optional
on page 22.
3. Run the Test
a)
on page 23.
b)
Correcting Resource Validation Errors
on page 24.
c)
on page 24.
d)
on page 24.
16 MTS TestSuite
