Suzuki SDS protocol
Channels received by SoloDL and EVO4 connected to Suzuki “SDS_Protocol” are:
ID CHANNEL NAME FUNCTION
ECU_1 SDS_RPM RPM
ECU_2 SDS_TPS Primary throttle position
ECU_3 SDS_GEAR Engaged gear
ECU_4 SDS_BATT_VOLT Battery Supply
ECU_5 SDS_CLT Engine coolant temperature
ECU_6 SDS_IAT Intake air temperature
ECU_7 SDS_MAP Manifold air pressure
ECU_8 SDS_BAROM Barometric pressure
ECU_9 SDS_BOOST Boost pressure
ECU_10 SDS_AFR Air/Fuel ratio
ECU_11 SDS_NEUT Neutral signal
ECU_12 SDS_CLUT Clutch switch
ECU_13 SDS_FUEL1_pw Fuel injector 1
ECU_14 SDS_FUEL2_pw Fuel injector 2
ECU_15 SDS_FUEL3_pw Fuel injector 3
ECU_16 SDS_FUEL4_pw Fuel injector 4
ECU_17 SDS_MS Mode selector
ECU_18 SDS_XON_ON XON switch
ECU_19 SDS_PAIR Air pressure
ECU_20 SDS_IGN_ANG Ignition angle
ECU_21 SDS_STP Secondary throttle position
