  • Text mode
  • Original mode
background image

13

1

2

4

7

6

5

8

Step. 6 Inspect all the components again:

9

Installation of Hard Drive

1. Enclosure with one side panel attached

2. Side panel

3. Drive bracket

4. One small screw

5. Two long screws with nylon collar

6. AC adapter

7. AC adapter cord

8. USB 2.0 A to B cable

9. FireWire (6-pin to 6-pin) cable

3
